UGREEN 15509 CM578 M.2 NVMe & SATA SSD Enclosure (USB-C 3.2 Gen 2, 10Gbps)

Product Description

The UGREEN 15509 CM578 M.2 NVMe & SATA SSD Enclosure is a versatile external enclosure designed to convert compatible M.2 SSDs into a portable, high-performance USB-C storage device. Whether you're backing up important files, editing videos, cloning drives, or expanding your storage, this enclosure delivers exceptional speed and reliability.

Featuring a USB 3.2 Gen 2 Type-C interface, it supports data transfer speeds of up to 10Gbps, enabling rapid file transfers when paired with a compatible NVMe SSD. The enclosure is compatible with both M.2 NVMe (PCIe) and M.2 SATA (NGFF) SSDs in 2230, 2242, 2260, and 2280 form factors, offering maximum flexibility for different storage upgrades.

Its tool-free slide-open design allows quick SSD installation without screws, while the premium aluminum alloy housing and integrated thermal pad provide efficient heat dissipation to maintain stable performance during extended use. The enclosure also supports UASP and TRIM for improved transfer speeds, lower CPU usage, and optimized SSD performance.

Key Features

• Supports both M.2 NVMe (PCIe) and M.2 SATA (NGFF) SSDs
• USB-C USB 3.2 Gen 2 interface with speeds up to 10Gbps
• Compatible with 2230 / 2242 / 2260 / 2280 M.2 SSDs
• Tool-free installation for quick SSD replacement
• Premium aluminum alloy enclosure for superior cooling
• Built-in thermal pad for improved heat dissipation
• Supports UASP and TRIM for faster, more efficient performance
• LED indicator for power and data activity
• Compact, lightweight, and ideal for portable storage

Specifications

• Brand: UGREEN
• Model: 15509 (CM578)
• Product Type: M.2 NVMe & SATA SSD Enclosure
• Host Interface: USB-C 3.2 Gen 2
• Maximum Transfer Speed: Up to 10Gbps
• Supported SSD Types: M.2 NVMe (PCIe) & M.2 SATA (NGFF)
• Supported SSD Sizes: 2230 / 2242 / 2260 / 2280
• Protocol Support: UASP, TRIM
• Chipset: RTL9210B
• Material: Aluminum Alloy
• Color: Gray

Compatibility

Compatible with Windows, macOS, Linux, Android, iPadOS, and USB-C enabled laptops, desktops, tablets, and smartphones. Works with compatible M.2 NVMe and M.2 SATA SSDs, making it ideal for backups, file transfers, system cloning, and portable storage.

Note: This enclosure supports M.2 NVMe and M.2 SATA SSDs only. It is not compatible with M.2 PCIe AHCI or mSATA SSDs. Actual transfer speeds depend on the installed SSD, USB host port, and connected device.

Package Includes

• 1 × UGREEN 15509 CM578 M.2 NVMe & SATA SSD Enclosure
• 1 × USB-C to USB-C Cable
• 1 × USB-C to USB-A Cable
• 1 × Thermal Pad
• 1 × User Manual
