UGREEN 40189 HDMI to USB-A & USB-C 4K Video Capture Card

Product Description

The UGREEN 40189 HDMI to USB-A & USB-C Video Capture Card is a compact and versatile device designed for recording and streaming high-definition video from HDMI sources. Whether you're live streaming gameplay, recording tutorials, hosting online classes, or capturing presentations, this capture card delivers smooth and reliable performance.

Supporting HDMI input up to 4K@60Hz and Full HD 1080P@30Hz capture output, it produces clear video with synchronized audio for professional-quality recordings. The built-in USB-A and USB-C dual interface makes it compatible with a wide range of laptops, desktops, tablets, and smartphones without requiring additional adapters.

With its plug-and-play design, no drivers or external power supply are needed. Simply connect your HDMI source, plug the capture card into your device, and start recording or streaming using popular software such as OBS Studio, XSplit, PotPlayer, or QuickTime.

Key Features

• HDMI video capture card with USB-A & USB-C dual interfaces
• Supports HDMI input up to 4K@60Hz
• Records and streams at 1080P@30Hz
• Simultaneous video and audio capture
• Plug-and-play operation with no drivers required
• Low-latency transmission for smooth live streaming
• Compact aluminum alloy housing for durability and heat dissipation
• Ideal for gaming, live streaming, online teaching, video conferencing, and content creation

Specifications

• Brand: UGREEN
• Model: 40189 (CM489)
• Product Type: HDMI Video Capture Card
• Input: HDMI
• Output: USB-A & USB-C
• Maximum HDMI Input Resolution: Up to 4K@60Hz
• Maximum Capture Resolution: 1920 × 1080 @ 30Hz
• Data Interface: USB 2.0
• Maximum Transfer Speed: Up to 480Mbps
• Audio Sampling Rate: 24-bit / 48kHz
• Material: Aluminum Alloy
• Color: Space Gray

Compatibility

Compatible with Windows, macOS, Linux, Android, and iPadOS 17 or later. Works with DSLRs, mirrorless cameras, camcorders, webcams, gaming consoles (PS5, PS4, Xbox, Nintendo Switch), and HDMI-equipped devices. Supports popular streaming and recording software including OBS Studio, XSplit, PotPlayer, QuickTime Player, and USB Camera Viewer.

Note: This capture card does not support HDCP-protected HDMI content. For PlayStation consoles, HDCP must be disabled before capturing gameplay. It supports 4K HDMI input, but the maximum recording/streaming resolution is 1080P@30Hz.

Package Includes

• 1 × UGREEN 40189 HDMI to USB-A & USB-C Video Capture Card
• 1 × User Manual
